MCT-200 Universal Motorcycle Scanner Support Multi-languages

Support motorcycle Model List:

HONDA,SYM,KYMCO,YAMAHA,PGO,SUZUKI,AEON,HARTFORD,KAWASAKI,VA,BENELLI,KTM.

MCT-200 Motocycle Scanner Support Protocol: K-line and CANBUS protocols

MCT-200 Motocycle Scanner Feature:

1. Retrieve ECU information
2. Display live data stream
3. Read fault codes
4. Clear fault codes
5. Component test
6. Special Function, such as: oil reset, ISC reset, CO adjustment etc
7. Support view waveforms and the numerical curve changes in data steam.

MCT-200 Motocycle Scanner Update:

 1. Update procedure is easy.

1) Connect the USB cable with PC, select "USB storage" option, the PC will detect the device as new flash disk.
2) Copy the update tool files to the disk, follow the tips to finish updating procedure. ( If your TF card can not be reset, please follow the tips to disconnect and connect power, then finish the updating procedure)

2. Device can be used as a USB flash disk

When connect USB cable with PC and select "USB storage" option,  the device can be used a USB flash disk which can save files based on your needs. Disable the flash disk on PC when finish using. The scanner will back to Main Menu automatically.

Replace TF Card and Battery

If the TF card is damaged or the battery is low, open the device back cover to replace.  Make sure the scanner is power off before replacing.

NOTE: MCT-200 Motorcycle scanner's TF card is FAT32 format. Please pay attention when formatting SD card. Otherwise the scanner will not work properly.

Package including:

1PC x MCT-200 Main Unit
1PC x Main Test Cable
1PC x SYM cable
1PC x KYMCO cable
1PC x SUZUKI-4PIN diagnostic cable
1PC x SUZUKI-6PIN diagnostic cable
1PC x PGO diagnostic cable
1PC x YAMAHA diagnostic cable
1PC x Battery Clamp
1PC x USB cable
1PC x HARTFORD diagnostic cable
1PC x AEON-1diagnostic cable
1PC x HONDA diagnostic cable
1PC x PIAGGIO/VESPA diagnostic cable
1PC x KAWASAKI-4PIN cable
1PC x KAWASAKI-4P/6PIN cable
1PC x TF Card(Standard Configuration 8G,Brand Sent randomly)
